Fits late 2021 & 2022 mufflers only.
Installation:
1. Apply a small bead of high temp silicone to the muffler outlet where the muffler insert will be installed.
2. Carefully install the insert into the muffler making sure it is fully seated and the ring groove in the muffler outlet is visible.
3. Separate the ring coils and insert the end without the bent tab into the groove. Note: Be sure
end of ring with bent tab is facing outward. This bend will aid future insert removal.
4. With the lower end of ring inserted into groove, slide screwdriver/pick counter-clockwise between the
winds of the clip to seat completely into the groove.
5. Clean the muffler canister then apply the spark arrestor decal to the top-rear of the canister.
Removal:
1. Insert a screwdriver or pick into the removal notch.
2. Use the tool to pry out the first end of the ring.
3. With the end of the clip now above the groove, slide the screwdriver/pick between the winds
clockwise until the lower end of the clip is released from the groove.
